PF
Product
  • PF is used for protecting monitor, cell phone, digital camera, PDA and other panels to avoid scratches. PF can also be used to increase stiffness of optical film or sheet material to protect materials preventing abnormal during slicing or other processing.
  • We have all kinds of PF products: PU/Silicone/Acrylic PF, High temp. PF, PI/COP PF.

Acrylic PF – Product Specification

Item ASD060 PCT065MY PCT060T
Thickness 60um 65um 60um
Adhesive Strength on SUS (g/in) 6±3 10±5 3~6
Surface Resistance of PET Side (Ω/□) 109~1010 — —
Surface Resistance of PSA Side (Ω/□) 1010~1011 — —
Item AS002ML AS003ML AS003C AS065E AS050E
Thickness 45um 53um 50um 65um 50um
Adhesive Strength on SUS (g/in) 8±2 3~5 12±2 14±2 8±2
Surface Resistance of PET Side (Ω/□) — — — 1010~1011 109~1010
Surface Resistance of PSA Side (Ω/□) 1010~1011 1010~1011 1011~1012 — 1010~1011
Customization available : Adhesive thickness 2um~25um；Adhesion 1g/25mm~1000g/25mm

PU PF - Product Specification

Item PCT060UC PCT060US PCU-612US PLU685UA PCU-012UM
Thickness 60um 60um 60um 150um 60um
Adhesive Strength on SUS (g/in) 2.5±2 2.5±2 2.5±2 ≦ 8 7±4
Surface Resistance of PSA Side (Ω/□) 1010~1011 108~1010 108~1010 109~1011 109~1011
Customization available : Adhesive thickness 10um~75um； Adhesion 1g/25mm~15g/25mm

Application

The protective film applied to product shipping or manufacturing process for the circuit board, the touch cell or the flat panel display industry.
