Precise Coating Product > ASF
ASF
Product
  • ASF which including adhesive/HC is used for glass TP to prevent glass fragments scattering during breaking.
  • ASF possess anti-scratch, anti-glare, anti-reflective and anti-shatter effect.

TAC ASF - Product Specification

Item Unit TR2G025N TF3J020N TY3G025Q TL2G025N TJ2G025N TH3G025N
Thickness Base Film µm 72 86 86 66 66 86
Adhesive µm 25 20 25 25 25 25
Peel Strength Adhesive Force – Alkaline Glass N/25mm ≧2 ≧3 ≧6 ≧6 ≧6 ≧6
Optical Properties Transmittance(T) % ≧94 ≧92 ≧93 ≧94 ≧94 ≧94
Reflectivity(Y) – ≦0.3 – 1.4 ±0.4 1.0 ±0.2 0.6 ±0.2 0.8 ±0.2
Haze % ≦1 6.5 ±2 8 ±2 ≦1 ≦1 6 ±2
Physical Property Contact Angle 。 >110 >100 >100 >100 >110 >110

SRF ASF - Product Specification

Item Unit FP3J020M FH3J020N
Thickness Base Film µm 80 ±5 86 ±5
Adhesive µm 20 ±5 20 ±5
Peel Strength Adhesive Force – Alkaline Glass N/25mm ≧3 ≧3
Optical Properties Transmittance(T) % ≧92 ≧94
Reflectivity(Y) – – 0.8 ±0.2
Haze % 0.7 ±0.4 7 ±1.5
Physical Property Contact Angle 。 < 65 109±5

Application

iPad, Smart Phone, Tablet, Automotive, and more.
